SUNGROW - THREE PHASE PV INVERTER - 110KW
- Description
- Key Features
- Technical Specifications
The Sungrow SG110CX-P2 is a high-power three-phase string inverter engineered for large commercial and industrial PV installations. Designed to support high-capacity arrays and complex string configurations, it delivers excellent efficiency, robust safety protection, and advanced monitoring. With a durable IP66 enclosure, multiple MPPTs, and installer-friendly design, the SG110CX-P2 provides reliable performance and simplified operation for long-term, large-scale solar systems.
-
110 kW three-phase output for large commercial and industrial PV systems
-
Multiple MPPT architecture for flexible array design and higher energy yield
-
High efficiency with maximum efficiency up to 98.7%
-
Integrated AFCI for enhanced fire safety protection
-
Built-in Type II DC & AC surge protection
-
Smart IV curve scanning with 24/7 live monitoring via iSolarCloud
-
Plug-and-play DC connections for faster, cleaner installation
-
IP66 enclosure with C5 anti-corrosion protection for harsh outdoor environments
| Specification | Value |
|---|---|
| Model | SG110CX-P2 |
| Rated AC Output Power | 110,000 W |
| Max. AC Output Apparent Power | 121,000 VA |
| Phase Configuration | Three-phase |
| Max. DC Input Voltage | 1,100 V |
| MPPT Operating Voltage Range | 200 – 1,000 V DC |
| Number of MPPTs | 9 |
| Max. PV Input Current | 48 A per MPPT |
| Max. DC Short-Circuit Current | 60 A per MPPT |
| Maximum Efficiency | 98.7% |
| Communication | WLAN / Ethernet / RS485 / DI / DO |
| Protection Rating | IP66 |
| Corrosion Protection | C5 |
| Cooling Method | Smart forced air cooling |
| Operating Temperature Range | −25 °C to +60 °C |
| Mounting Method | Wall-mounting bracket |
| Compliance | IEC / EN 62109-1/2 |
