SUNGROW - THREE-PHASE HV HYBRID INVERTER - 15KW
- Description
- Key Features
- Technical Specifications
The Sungrow SH15T is a high-performance three-phase hybrid inverter designed for larger residential and light commercial energy storage systems. Combining solar generation, battery storage, and full backup capability in a single unit, it ensures seamless power continuity during grid outages. With fast charge and discharge performance, flexible system design, and installer-friendly features, the SH15T delivers reliable energy independence with long-term operational stability.
-
15 kW three-phase hybrid inverter with battery integration
-
Built-in bypass for whole-home backup functionality
-
Seamless transition to backup mode (<10 ms) during grid outages
-
Supports 100% unbalanced output in both on-grid and backup modes
-
High charge and discharge current capability for demanding loads
-
Plug-and-play installation for faster commissioning
-
Quiet operation suitable for indoor or outdoor installation
-
Advanced safety protection with IP65 and C5 corrosion rating
| Specification | Value |
|---|---|
| Model | SH15T |
| Rated AC Output Power | 15,000 W |
| Rated AC Output Apparent Power | 15,000 VA |
| Phase Configuration | Three-phase |
| Max. PV Input Voltage | 1,000 V |
| MPPT Operating Voltage Range | 150 – 950 V DC |
| Number of MPPTs | 3 |
| Max. PV Input Current | 30 A |
| Battery Type | Li-ion |
| Battery Voltage Range | 100 – 700 V |
| Max. Charge / Discharge Current | 50 A / 50 A |
| Backup Switch Time | < 10 ms |
| Rated Backup Output Power | 15,000 W |
| Peak Backup Output Power | Up to 25,500 VA (10 s) |
| Communication | RS485 / WLAN / Ethernet / CAN |
| Protection Rating | IP65 |
| Cooling Method | Natural convection |
| Operating Temperature Range | −25 °C to +60 °C |
| Dimensions (W × H × D) | 620 × 480 × 245 mm |
| Weight | As per Sungrow specification |
| Mounting Method | Wall-mounting bracket |
| Warranty | As per Sungrow inverter warranty documentation |
| Compliance | IEC / EN 62109 |
