5KW Hybrid Inverter/10kWh Battery 48V 2MPPT, WiFi Plug Included
5KW Hybrid Inverter/10kWh Battery 48V 2MPPT, WiFi Plug Included

5KW Hybrid Inverter/10kWh Battery 48V 2MPPT, WiFi Plug Included

SKU Chelion 5kW/10kW All in One
Call for availability
  • Description
  • Key Features
  • Technical Specifications

The Chelion 5 kW Hybrid Inverter with 10 kWh Battery is a smart energy storage solution built for New Zealand homes. It combines a high-efficiency single-phase inverter with integrated 10 kWh lithium-ion storage, providing seamless solar self-consumption, backup power, and grid support. Compact, reliable, and standards-compliant, it is the ideal all-in-one solution for residential solar + storage projects.

5kW Hybrid Inverter/10kWh Battery Data Sheet

  • 5,000 W inverter output — ideal for residential applications.

  • 10 kWh lithium-ion battery for reliable daily storage.

  • High round-trip efficiency (~97.5% inverter, >90% battery).

  • Battery-ready hybrid design with built-in DC-coupled battery port.

  • Whole-home backup support with automatic switchover (<3 s).

  • Active safety protections: arc-fault detection, surge, overload, and residual current monitoring.

  • Dual MPPTs for flexible solar string layouts and higher yields.

  • Outdoor-ready IP66 enclosure, robust against NZ environmental conditions.

  • Standards compliance: AS/NZS 4777.2:2020+A1; IEC 62109-1/-2.

Specification Value
Rated Inverter Output (AC) 5,000 W
Output Phase / Connection Single-phase (L + N + PE)
Output Voltage 220 / 230 / 240 V AC
Rated AC Output Current ~22–23 A
Frequency 50 / 60 Hz
Max DC Input Voltage 600 V DC
MPPT Voltage Range 40 – 560 V DC
Number of MPPTs / Strings 2 MPPTs / 4 inputs
Max Input Current per MPPT 12.5 A
Battery Capacity 10 kWh lithium-ion
Battery Voltage Range ~350 – 600 V DC
Max Battery Charge/Discharge Power ~5,000 W
Efficiency (Peak / Euro Weighted) ~98% / ~97.5%
Backup Function Whole-home backup, switchover <3 s
Enclosure Rating IP66
Operating Temperature –25 °C to +60 °C
Dimensions (W × H × D) ~425 × 376 × 150 mm (inverter), ~500 × 700 × 200 mm (battery)
Weight ~15 kg (inverter), ~100 kg (battery)
Standards Compliance AS/NZS 4777.2:2020+A1; IEC 62109-1/-2
