Entelar Energy Smart String Inverter, Three Phase, Max output 29,900w, 4 x MPPT / 8 x Inputs
Entelar Energy Smart String Inverter, Three Phase, Max output 29,900w, 4 x MPPT / 8 x Inputs

Entelar Energy Smart String Inverter, Three Phase, Max output 29,900w, 4 x MPPT / 8 x Inputs

SKU EESOLAR-29.9KTL-M3
Call for availability
  • Description
  • Key Features
  • Technical Specifications

The Entelar EESOLAR-29.9KTL-M3 is a powerful three-phase smart string inverter built for large commercial or industrial solar PV installations. It supports up to eight PV string inputs and four MPPT trackers, delivering high efficiency, intelligent monitoring, and robust protection. Designed for reliability in demanding environments, it provides excellent performance with minimal maintenance.

EESOLAR-29.9KTL-M3 Data Sheet

  • Max efficiency around 98.6-98.7%, minimizing energy loss.

  • Intelligent monitoring with 8 strings for fast fault-detection and improved string mismatch handling.

  • Fuse-free design, reducing maintenance and improving reliability.

  • Integrated DC switch for safety and convenience during maintenance.

  • Natural cooling design (no need for active cooling fans) for quiet operation and lower maintenance.

  • Built-in WiFi / WLAN + support for RS485 and other communication options.

  • High protection rating (IP66) for durability in harsh outdoor environments.

Specification Value
Rated Output Power (Active) 29,900 W
Maximum Apparent Power 29,900 VA
Efficiency (Peak) ~ 98.65 %
European Efficiency ~ 98.4 %
Number of MPPTs 4
Number of String Inputs 8
Maximum DC Input Power 44,850 W
Maximum Input Voltage 1,100 V DC
Max Current per MPPT 27 A
Max Short-Circuit Current per MPPT 40 A
MPPT Voltage Range (operating) 200-1,000 V DC
Full-load MPPT Voltage Range ≈ 500-800 V DC (at 400 V AC output)
Rated Output Voltage / Voltage Configuration 230 V (400 V AC), 3W/N+PE (three-phase)
Rated Output Current ≈ 43.2 A (at 400 V AC)
Power Factor 0.8 leading to 0.8 lagging
Total Harmonic Distortion (THDi) < 3% under rated conditions
Protection Features DC reverse-connection, String fault detection, Type II DC & AC surge protection, etc.
Display & Communication LED indicator; WLAN + App; RS485; etc.
Dimensions (W x H x D) 640 × 530 × 270 mm
Net Weight ~ 43 kg
Operating Temp. Range -25 °C to +60 °C (derated above +45 °C)
Protection / Ingress Rating IP66
