PV-ezRack ComT, Front Leg Assembly, 10°, with Z-Module and Grounding Pins, version 2
SKU FL-COMT/Z/G/10V2
Call for availability
- Description
- Key Features
- Technical Specifications
The Clenergy PV-ezRack FL-COMT/Z/G/10V2 is the 10° front leg assembly for the ComT 2.0 mounting system. It is designed for tin and flat roof applications and fixes into the top channel of ECO-Rail or T50/T110 rails using the supplied Z-module.
- 10° front leg assembly: Front leg for Clenergy ComT 2.0 tilt mounting.
- Rail compatibility: Fixes into the top channel of ECO-Rail or T50/T110 rails.
- Z-module fixing: Uses a Z-module for rail attachment.
- Grounding pins: Listed by Clenergy as the version with grounding pins.
| Specification | Details |
|---|---|
| Part Number | FL-COMT/Z/G/10V2 |
| Product Type | ComT 2.0 front leg assembly, 10°, version 2 |
| Roof Type | Tin and flat roof |
| Fixing Method | Top channel of ECO-Rail or T50/T110 rails with Z-module |
| Maximum PV Panel Size | Up to 2400 × 1200 mm |
| Weight | 0.145 kg |
| Material | AL6005-T5 aluminium |
| Colour / Finish | Silver, half anodised, no less than 10 μm |
| Packaging | 30 units per pack; 4 packs (120 units) per carton |
| Standard | AS/NZS 1170.2:2011 |
