PV-ezRack SolarRoof ,Tin Interface (1 Unit)
SKU ER-I-05
Call for availability
- Description
The Clenergy PV-ezRack ER-I-05 is a tin roof interface for connecting compatible SolarRoof rails to metal or timber purlins. The assembly includes the roof hook, rail connection hardware, rubber pad and Buildex roof fastener.
View the current Clenergy ER-I-05 datasheet download
Key Features
- Purpose-made Clenergy SolarRoof tin interface
- Includes a 38 × 38 × 2 mm rubber pad
- Z-Module connection for compatible PV-ezRack rail
- Supplied with Buildex 14-11 × 70 mm Hex Head Zips screw
Technical Specifications
| Part number | ER-I-05 |
| Product type | Tin roof interface |
| Rail connection | Z-Module |
| Rail fastener | M8 × 28 mm hex socket head bolt |
| Roof fastener | Buildex 14-11 × 70 mm Hex Head Zips screw |
| Rubber pad | 38 × 38 × 2 mm |
| Included washers | 8 mm flat washer and A2 lock washer |
